Pedal Commander – Throttle Response Controller 5th Gen Toyota 4Runner
After I installed this, I said; WOW, HOLY SH**, THIS IS EPIC, WTF, INSANE.
I drove the supercharged 4Runner when we visited with Magnuson, so yes I understand what real 4Runner power feels like. The Supercharged 4Runner was awesome. But for the small price on the throttle controller compared to a supercharger, this thing is awesome. It sounds crazy to even mention this product in the same paragraph as a supercharger but it’s valid. The product is seriously impressive.
With that being said, let’s jump into the overview.
What is the Pedal Commander/ Throttle Controller?
This unit is a small electrical component that plugs straight into your gas pedal’s assembly. The Pedal Commander is designed to increase your throttle response. With the unit installed, you will have absolutely no lag time on your gas pedal and complete control of power in your 4Runner.
A throttle controller will eliminate all factory settings for limiting your throttle response and take all those settings from the ECU into the new controller, allowing you to adjust your throttle response on the fly.
Pedal Commander/ Throttle Controller Model:
- The PC for 5th Gen: Check Price
Just remember there are different models for different year 4Runners. The link above will take you straight to the correct model. Get increased performance or save fuel up to 20%!
Stock 5th Gen 4Runner Gas Pedal Control?
In our stock 4Runner, we have a very “mushy” gas pedal. You really need to push down on our gas pedal to get our 4Runner’s to do anything. With the PC installed, this will be eliminated. There is an instant jump in power. The difference is truly impressive. If you like to drive your 4Runner fast, and love power, then you need to grab one of these.
The Pedal Commander combined with an aftermarket 4Runner exhaust and a TRD Intake really makes a difference as well. As you rev up quickly with the PC, you can really feel the power from the intake and the exhaust instantaneously. The PC really brings your intake and exhaust to life. After we install the Doug Thorley Headers, things are going to start getting interesting.
Is the Pedal Commander worth it?
I think so, YES. After installing many different 4Runner performance mods, we have something to stack it against. If you have an Intake or an Exhaust installed on your 4Runner, I would say 100%, YES grab one of these.
You will have fun. Obviously, there is no HP gain, but it definitely makes your 4Runner much more fun to drive. With an Intake and Exhaust, you can feel and hear the true performance of these performance parts.
If you do not have an Intake or an Exhaust installed on your 4Runner, you can still install one of these. The only difference is that you will not hear and feel your intake/ exhaust as much. Either way, intake and exhaust or no intake and exhaust, this is an awesome little unit.
Seriously impressed.
Pedal Commander Features & Settings
- Eco-Mode
- Daily Driving
- Spirited Driving (Sport)
- Racing Purposes (Sport+)
- Decrease Response
- Increase Response
- On/Off Program Buttons
The Pedal Commander offers four program selections and they vary from eco-mode, city, sport, and sport+ which all have their own set of features and benefits. Each mode has nine different sensitivity levels and up to 36 levels in total, which can be accessed by pressing the program button.
- 4Runner Stock: When all of the units lights are off, your 4Runner is operating stock.
- 4Runner Eco-Mode: Eco-Mode is used for fuel savings, smoother driving, better traction and heavy weather conditions and can also be used for off-road purposes. The unit will not be active wall cruise control system is engaged.
- 4Runner City: The Pedal Commander’s city mode is perfect for daily driving.
- 4Runner Sport: enable in Sport-Mode is great for what the unit calls spirited driving, which must mean aggressive driving.
- 4Runner and Sport+: Running your 4Runner in the Pedal Commander’s sport+ mode is mentioned as “great for racing at the track“. Now, we all know we’re not going to be racing at the track so sport+ is going to be used if you’re on the freeway or driving on long stretches of road, and really want to push it. Running the Pedal Commander in sport+ mode is likely to decrease your MPGs big time.
Note from pedal commander: The Pedal Commander is intended to boost your 4Runner’s performance, including its speed and acceleration capabilities. Pedal Commander is not designed to increase your 4Runner’s horsepower. With all of the features that the Pedal Commander offers, they encourage you to drive safely and never use Pedal Commander other than it’s intended instructions.
Pedal Commander Installation Instructions
Installation Instructions from Pedal Commander
The installation instructions on the pedal commander pretty straightforward. You want to start by turning off your 4Runner ignition. Second and a very important note is that if your 4Runner has a keyless entry (which most 5th Gen 4Runner’s do), keep the key fob at least 35 feet away.
The signal from your key fob can give power to your 4Runner, so you want to make sure that you turn off your ignition and keep your key fob away from your 4Runner before installation.
Start by locating your Accelerator (Gas) pedal assembly plug connection. This is the plug above your gas pedal. Remove the plug on your gas pedal, and then plug the male and female connectors on the Pedal Commander into their coordinating plugs on the gas pedal assembly.
Make sure the cables are tucked in place so they do not affect or cause danger while you’re driving. Route the Pedal Commander to where you can access it easily.
Preferably, you want to mount the Pedal Commander somewhere on the dash of your 4Runner to where you can easily adjust the controls while driving on the fly.
Use the include alcohol wipes to clean the area where you would like to mount the bracket.
Apply the Velcro to the bracket and clean area. Put the Pedal Commander into the bracket and you’re all set. If you need visual assistance for installing the Pedal Commander you can visit the Pedal Commander website at pedalcommander.com.
SENSOR NOTE: If you unplug the gas pedal too soon from your 4Runner you’ll receive a check engine light because the ECU still has power and will detect the sensor as defective.
SERVICE NOTE: If you’re visiting a dealership for regular service, you do not need to remove the pedal commander. Just turn it off and tuck it away so that you can put it back into its bracket after your service is complete. What is Pedal Commander trying to say on this one? Well, it probably voids some type of warranty after installing it.
Pedal Commander Step By Step Install – 4Runner
Step #1 – Locate Gas Pedal Plug
The pedal assembly plug connection is mounted directly on top of your Gas Pedal.
Step #2 – Unplug from Gas Pedal
Unplug the pedal assembly plug connection from the top of your Gas Pedal. I took off the gas pedal using a 10mm socket. There are two (one on each side of the gas pedal). You do not need to take off your gas pedal.
But the pedal assembly plug connection is hard to access. If you find you are having a hard time pressing down on the tab where the red arrow is pointed, just remove the gas pedal. It’s easy.
We really just took the gas pedal off to get some better shots, but we really didn’t even need to do that.
Step #3 – Plug In Female Outlet
Step #4 – Plug In Male Outlet
Step #5 – Mount Your Pedal Commander Bracket
You do not have to mount your Pedal Commander bracket right here. You can mount the bracket wherever you want. We just found this to pretty a pretty quick and easy installation spot. If you find somewhere better, please let us know.
Pedal Commander to Bracket
After you have mounted your Pedal Commander onto its bracket, you will have some loose wires. From underneath the dash, Ziptie together the loose wires together. There are not a ton of options for securing the wire to the 4Runner. I zip tied the wiring together and it was tucked underneath the dash enough to keep everything out of the way.
Pedal Commander Model:
- The Pedal Commander for 5th Gen: Check Price
This is a pretty simple little install. The hardest part is figuring out where to mount the bracket. After you install the Pedal Commander, play with the settings and see what you are most comfortable with.
- Sport+ Mode was out of control. The instantaneous power production was unbelievable.
- Sport Mode had advanced power production but was not as intense as the Sport+. This was a very manageable mode and also made driving the 4Runner more exciting.
- City Mode was more along the lines of stock with a slight boost off the line.
- Eco Mode really did make our MPGs go up. We are running 34″ tires and our MPGs were sitting at 10 MPG around town. MPGs on town went up to 12.5 which is right along the lines with what they quote at 20% fuel savings.
Whatever you are buying the Pedal Commander for, you will be happy. There is a reason why there are so many 5 star reviews on this product.
